Products
Digifoil 33
Foil without Die
Foil material sticks to the tonner base, therefore the die or plate like stamping process is not required. Both big images and detailed images are possible to be foiled. Multiple colors of foil are available.
Compact Body
Table top type and power supply is only 100V.
Paper size is A5 ~ A3
Possible to adjust the temperature and speed depending on work.
New method Dry Coating
Clear material is transferred onto the whole paper and makes a gloss effect. Very thin material and unnecessary to be-trimmed the paper after the process.
Liner is also unnecessary. No curl problem.
Eco Friendly
Coating is not a required type, therefore the maintenance is easy, and no smell problem.
Also, the coated material is not film, therefore possible to recycle it as paper.
Digital single pass printer
2023 New Digital Single Pass Corrugated Printer 300mm Printing Width Inkjet Pizza Box Kraft Tote Bags Printing Direct To Printing Paper Packaging Printer
Product name : Digital single pass printer
Brand : Sunthinks
Printer Type : Single pass inkjet printer
Printhead : A3 pagewide printhead
Ink Type : Pigment ink & Dye ink
Operating System : PLC
Power : 3.5kw
Printing Speed : 30m/min
Printing Size : 1~300mm
Max Material thickness : 80mm
Printer Size(L*W*H) : 1126mm*2150mm*1500mm
Goss Weight : 600kg
Application : Corrugated box, paper bag, non-woven fabric, canvas, wood board and other materials printing
DTM – Eddie Edible Ink Printer
Discover the versatile Eddie Edible Ink Printer. High-resolution printing up to 1200 x 1200 dpi. Fast, efficient, and perfect for edible creations.
Print Method: Thermal inkjet with edible ink
Max. Print Speed: 5 – 6 items per minute,
varies by item size and print
Media Width: Up to 89 mm
Media Thickness: Up to 25mm
Print Resolution: 1200 x 1200 dpi
Specification
| Print Method: | Thermal inkjet with edible ink |
| Print Resolution: | 1200 x 1200 dpi native; up to 1200 x 4800 dpi |
| Print Speeds: | Varies by item size and print (e.g. for objects with Ø 89 mm 5-6 pcs./minute) |
| Inks: | Single high capacity CMY ink cartridge, process black |
| Dyes Contained in the CMY Cartridge: | Cyan: Blue #1 – Brilliant Blue FCF (E133) Magenta: Carmoisine – Azorubin (E122) Yellow: Yellow #5 – Tartrazin (E102), Yellow #6 – Sunset Yellow FCF (E110) For more information on the ingredients please see: dtm-print.eu/europe/rohs |
| Printhead: | Included in cartridge |
| Colours: | 16.7 million |
| Print Width: | up to 120 mm |
| Item Width: | Carousel: 89 – 105 mm (with spacer 63.5 – 86.68 mm) DTM Carousel Trays: 0 – 89 mm Platform Kit: 0 – 120 mm DTM Trays: 0 – 120 mm |
| Item Height/Thickness: | Carousel: 3 – 19 mm DTM Carousel Trays: 3 – 19 mm Platform Kit: 30 – 60 mm (use raiser for Carousel or DTM Trays) DTM Trays: 2 – 27 mm |
| Feeding Mechanism: | Platform Kit & DTM Trays (manual): The feeding arm feeds the printed objects into the printer, which automatically adjusts the height, prints the objects and then presents them. Carousel & DTM Carousel Trays (automatic): The objects are conveyed from the carousel plate into the printer and placed back on the plate when printing is finished. |
| Ink Level Warning: | Calculates actual number of prints remaining based upon ink usage of graphics being printed. |
| Indicator Lights: | Power, Ink |
| Controls: | Load/Unload, Pause |
| Operating Systems: | Windows 7 – 11 Mac OS X 10.11 – macOS 12 |
| Data Interface/Connections: | USB 2.0 |
| Design Software: | BarTender UltraLite and NiceLabel Free DTM Version (Windows) Belight Swift Publisher (Mac) Can also be used with most other popular label design & graphics programs. |
| Power Requirements: | 100-240 V AC (50/60 Hz), 36 W or 12 V DC, 3 A |
| Certifications: | UL, UL-C, FCC Class A, NSF/ANSI Standard 18 Manual Food and Beverage Equipment. 21CFR: US Code of Federal Regulations, Title 21 – US FDA EU 231/2012: Regulation (EU) No 231/2012 laying down specifications for food additives |
| Weight: | Total weight 11.3 kg Printer: 8.5 kg Carousel and base: 2.8 kg |
| Dimensions (WxHxD): | Total: 406 mm x 181 mm x 792 mm Printer: 317 mm x 181 mm x 474 mm Carousel: 406 mm x 72 mm x 421 mm |
| Operating Temperature: | 10 °C to 35 °C |
| Operating Humidity: | 10 % to 60 % RH (non-condensing) |
| What’s in the Box: | Eddie Edible Ink Printer, edible ink cartridge (053499), carousel (base + plate), USB 2.0 cable, EU power cord and instructions Design Software and printer driver can be downloaded from the DTM Print website. |
| Recommended Accessoires: | Different trays and spacers are available for both automatic and manual feed. These allow printing on any objects within the mentioned specifications. |
| Warranty: | 36 months (after product registration for devices, purchased in EU, EFTA countries and UK) |
| Manufacturer: | Primera Technology, Inc. |
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-CT0001
Carousel Tray x 12 pcs |
053259DTM-CT0002
Carousel Tray x 12 pcs |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-CT0003
Carousel Tray x 12 pcs |
053259DTM-CT0004
Carousel Tray x 12 pcs |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-CT0005
Carousel Tray x 12 pcs |
053259DTM-CT0006
Carousel Tray x 12 pcs |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-M0001
Manual Tray 12 cm square |
053259DTM-M0002
Manual Tray 12 cm square |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-M0003
Manual Tray 12 cm square |
053259DTM-M0004
Manual Tray 12 cm square |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-M0005
Manual Tray 12 cm square |
053259DTM-M0006
Manual Tray 12 cm square |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-M0007
Manual Tray 12 cm square |
053259DTM-M0008
Manual Tray 12 cm square |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-M0009
Manual Tray 12 cm square |
053259DTM-M0010
Manual Tray 12 cm square |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-M0011
Manual Tray 12 cm square |
053259DTM-M0012
Manual Tray 12 cm square |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-M0013
Manual Tray 12 cm square |
053259DTM-M0014
Manual Tray 12 cm square |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-M0015
Manual Tray 12 cm square |
053259DTM-M0016
Manual Tray 12 cm square |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-M0017
Manual Tray 12 cm square |
053259DTM-M0018
Manual Tray 12 cm square |
||
| TRAY | DOWNLOAD TEMPLATE | TRAY | DOWNLOAD TEMPLATE |
| 053259DTM-M0019
Manual Tray 12 cm square |
