Foil without Die

Foil material sticks to the tonner base, therefore the die or plate like stamping process is not required. Both big images and detailed images are possible to be foiled. Multiple colors of foil are available.

Compact Body

Table top type and power supply is only 100V.
Paper size is A5 ~ A3
Possible to adjust the temperature and speed depending on work.

New method Dry Coating

Clear material is transferred onto the whole paper and makes a gloss effect. Very thin material and unnecessary to be-trimmed the paper after the process.
Liner is also unnecessary. No curl problem.

Eco Friendly

Coating is not a required type, therefore the maintenance is easy, and no smell problem.
Also, the coated material is not film, therefore possible to recycle it as paper.

FX810 Foil 4” – 10“ inch (108 – 255 mm)

Print Method: Thermal transfer & Direct thermal
Max. Print Speed: 101.6 mm (4”) per second
Max. Print Width: 219.5 mm (8.64”)
Print Length: 1016 mm (40”)
Media Width: 108 - 255 mm (4” - 10“)
Media Types: Roll-fed continuous, die-cut or blackmark labels or tags; roll-fed tags with punched hole
Print Resolution: 300 dpi (12 dots/mm)

Using digital LED together with dry toner technology, the Pro1050 offers a unique fifth colour or ‘CMYK+W’ option, allowing for greater flexibility in your label design. Printing on transparent or coloured label media is now easy by printing an opaque white background under the CMYK image.

• Profitable on-demand in-house label printing
• Fifth colour or CMYK+W option brings a new colour dimension to labels
• Versatile media handling
• Water/chemical and UV fading resistant printing

Rewinder CAT 3 ACH

Features

• Handles labels up to 155mm wide
• Roll diameter capacity up to 280mm
• Adjustable core holder from 25 to 101mm
• Speed up to 125cm/sec

Category: label accessories

Desktop Digital finishing system

Label Maker R14 is a compact digital label finishing system that  used to unwind and laminate the labels, digital die cutting, excess label material removal around die-cut shape and slit. This machine offers professional cut and finish of labels.

This system is accurate label finisher using cutting plotter technology and allows you to cut different types of materials and shapes without additional investment on dies.

To provide maximum cutting speed and avoiding synchronization issues, the system equipped with a cutter management tool that works inline with a camera to form an integrated optical black-mark registration.

Label Maker R14 features smooth workflow, flexibility and limitless variations in label design. This digital label finisher is a perfect short run solution for  color label printers and presses.

Benefits

• Short run in-house label production reducing cost and inventory requirements
• Producing full bleed labels will no longer be a nightmare
• Laminating option for labels for added durability (no need for special media)
• No need to order pre-die cut label rolls
• Desktop size unit
• No need to set up a minimum gap between labels when printing in full bleed (Saves media).

Main Features

• Automatic, Auto sheet media feeding and finishing
• Special software to provide accurate alignment of contour die cut lines
• High speed Camera that detects 2-point reference marks for cut alignment
• Ability to do half (kiss) cutting, perforation and dashed line cutting

Increases production efficiency by automatic reloading

The cutting plotter is reloaded with media by the automatic sheet feeding system. The cutting process is provided by this loading-unloading mechanism. It enables to significantly improve productivity in finishing a high quantity of media with the same digital die-cut. The following steps are automatically repeated continuity until a specific number of copies are made
