1000- 12000W Combined Laser Cutting Machine
1000W Combined Laser Cutting Machine
One Machine Two Function for Dual Use
Metal sheet and Metal tube Cutting
One Machine Two Function for Dual Use
Metal sheet and Metal tube Cutting
Technical Parameters
1000W Combined Laser Cutting Machine
1000W Combined Laser Cutting Machine photos
1000W Combined Laser Cutting Machine Technical Parameter
| Product Name | Combined Laser Cutting Machine | Laser Source | 1000W MAXPHOTONICS |
| Laser Head | Raytools BM110 | Water Chiller | Hanli Brand |
| Guidance Rail and Rack | HIWIN & YYC | Chuck Size | 120mm/ 170mm / 250mm |
| Servo Motor | Inovance / Yaskawa | Reducer | Shimpo/ Motoreducer |
| Sheet Cutting Part | 3×1.5m / 4×1.5m / 4x2m / 6x2m, etc | Tube Cutting Part | 6m length, 10-115mm/ 16-165mm/
16-240mm diameter |
| POSITIONING ACCURACY | ±0.03/1000mm | REPEAT POSITIONING ACCURACY | ±0.02mm |
| 1000W Cutting capacity in Batch Processing | 8mm CS, 4mm SS, 2mm AL, and 2mm Copper | ||
Rear Chuck And Front Chuck Photos, Variable diameter Nylon Wheel Support For Tube
Metal Sheet Cutting Part Machine Body and Strong Aluminum Cast Beam
